specMACS on (AC)3 campaign (March/April 2022)

general remarks

We had problems with the shutter of the VNIR camera which was closed during most of the flights. When the shutter was open is indicated below.

summary of research flights

datenamereportremarks
2022-02-21 HALO-0221
  • EMI Flight
  • icing of the window
2022-02-25 HALO-0225
  • RF00 - Test flight
  • icing of the window
2022-03-11 HALO-0311
  • RF01 - Transfer flight
  • icing of the window
2022-03-12 HALO-0312
  • RF02 - warm air intrusion day 1
  • only little icing of the window
  • kerosene on the window at the end of the flight
2022-03-13 HALO-0313
  • RF03 - warm air intrusion day 2
  • VNIR shutter open
2022-03-14 HALO-0314
  • RF04 - warm air intrusion day 3
2022-03-15 HALO-0315
  • RF05 - atmospheric river day 1
  • VNIR shutter open
2022-03-16 HALO-0316
  • RF06 - atmospheric river day 2
2022-03-20 HALO-0320
  • RF07 - day before cold air outbreak
2022-03-21 HALO-0321
  • RF08 - cold air outbreak day 1
  • hydraulic oil on the window from about 12 UTC
2022-03-28 HALO-0328
  • RF09 - cold air outbreak
  • convergence along sea ice border
2022-03-29 HALO-0329
  • RF10 - cold air outbreak
  • eastern branch and first circle
2022-03-30 HALO-0330
  • RF11 - cold air outbreak
  • lagrangian mesoscale divergence circles
2022-04-01 HALO-0401
  • RF12 - cold air outbreak
  • rectangular divergence pattern at sea ice edge
2022-04-04 HALO-0404
  • RF13 - ice edge, cirrus, water vapour
2022-04-07 HALO-0407
  • RF14 - arctic cirrus
2022-04-08 HALO-0408
  • RF15 - polar low
  • VNIR shutter open
2022-04-10 HALO-0410
  • RF16 - moist advection, arctic cirrus
2022-04-11 HALO-0411
  • RF17 - arctic cirrus
  • VNIR shutter open
  • dirt on the window due to take off on a wet and dirty runway
2022-04-12 HALO-0412
  • RF18 - arctic cirrus
2022-04-14 HALO-0414
  • Transfer flight

specMACS products

Products derived from the specMACS data captured during (AC)3 campaign can be downloaded here.
Maps of the specMACS data, together with MODIS and MISR data, can be accessed here.

the specMACS instrument

specMACS is a hyperspectral imager, capturing one image line at a time. It is sensitive in the range of approx. 400nm to 2500nm and has a field of view of approximately 35°. During (AC)3 it is mounted on the HALO aircraft facing downwards and is accompanied by two 2D polarization resolving cameras. More information can be found in Ewald et al. (2016).
